Desktop Pulse Oxygen Meter RSD 7500 Pulse Rate SpO2 Probe CE Standard

Product Details:

Place of Origin:	China
Brand Name:	RONSEDA
Certification:	CE and ISO
Model Number:	RSD 7500

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Usd 150 / Set
Packaging Details:	Box
Delivery Time:	5-10 Working Days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	1000 Set / Month

Contact Now

Detailed Product Description

Parameter:	SPO2,PR	Weight:	2KG
Dimension:	264mm(W) X 95mm(H) X 172mm(D)	Standard:	Pulse Oximeter
Approval:	CE And ISO	Opreation Temperature::	5～40℃
High Light:	handheld pulse oximeter , most accurate finger pulse oximeter

Desktop Pulse Oximeter RSD 7500 Pulse Rate SpO2 Probe

FEATURES:

* Bright, Easy-to-Read Large LED Display

* Durable, Compact and Lightweight

* Long-life Internal Rechargeable Battery for

* Uninterrupted Monitoring

* Accurate and Reliable During Low Perfusion and Motion

* Audible/Visual Three Level Alarms with Alarm Volume Control

* 72-hour Data Memory Allowing On-screen Viewing of SpO2 and Pulse Rate Trends

* Suitable for Adult, Pediatric and Neonate

P/N:

RSD 7500

INTRODUCTION:

* SpO2 Accuracy:

No Motion:

Adults, Pediatrics: 70~100% ±2%

0~69% unspecified

Neonates: 70~100% ±3%

0~69% unspecified

Motion:

Adults, Pediatrics: 70~100% ±3%

0~69% unspecified

Neonates: 70~100% ±4%

0~69% unspecified

Low Perfusion:

Adults, Pediatrics: 70~100% ±3%

0~69% unspecified

Neonates: 70~100% ±4%

0~69% unspecified

* Pulse Rate Accuracy

No Motion:

Adults, Pediatrics, Neonates: ±3%

Motion:

Adults, Pediatrics, Neonates: ±5%

Low Perfusion:

Adults, Pediatrics, Neonates: ±5%

* Displays and Indicators

SpO2, Pulse Rate and Pulse Strength Bar

Pulse Search Indicator

Low Perfusion and Motion Warning Indicator

Alarm Silence Indicator

AC Power and Battery Charge Indicator

Low Battery Warning Indicator

Sensor Disconnect and Sensor off Warning Indicator

* Alarm

Audible/Visual Alarms for High/Low SpO2 and PR

Audible/Visual Alarms for Low-Battery

Alarm Limits Adjustable

Alarm Volume Adjustable

Pulse Search Indicator

Alarm Silence Interval:30,60,90and120sec and OFF

Low Perfusion and Motion Warning Indicator

Sensor Disconnect Alarm

Sensor off Alarm

* Performance Measurement Range

SpO2:0～100%

Pulse Rate: 20bpm~250bpm

* Environment

Opreation Temperature: 5～40℃

41~104℉

Humidity: ≤80%

Altitude: -390~5,000m(-1,280~16,404ft)

Transport/Storage Temperature:

-20～+70℃ (-4℉~158℉)

Humidity: ≤95%

* Output

RS-232 Serial Port for Digital Output

Nurse Call Function

* Electrical Instrument

Power Requirements:

100~240VAC, 50/60Hz, 20VA

Fuse Rating: 1.0A

* Battery

Internal Battery: 12V 3.6Ah　

Battery Capacity: ≥ 24 hours

* Physical Characteristics

Dimensions:

264mm(W) x 95mm(H) x 172mm(D)

[10.39in(W) x 3.74in(H) x 6.77in(D)

Net Weight: 2.5kg/5.5ib

Gross Weight: 3.5kg/7.7ib

*Compliance

SpO2: ISO9919:2005　

Safety Standards:

En60601-1: 1990+A1: 1993+A2: 1995+A13: 1996 Type BF-Applied

IPX1 Approved

Alarm: IEC60601-1-1-8: 2005

EMC:EN60601-1-2: 2001, Group1 Class A

Environment: WEEE(2002/96/EC)

* Optional Part

Thermal Array Recorder to print Graphical and Tabular Trend

WARRANTY:

One years after receiving item.
