Wireless Bluetooth Handheld Pulse Oxygen Meter Small 10X20X15CM Dimension

Product Details:

Place of Origin:	China
Brand Name:	RONSEDA
Certification:	CE and ISO
Model Number:	RSD 7800

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Usd 30 / Set
Packaging Details:	Box
Delivery Time:	5-10 Working Days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	1000 Set / Month

Contact Now

Detailed Product Description

Parameter:	SPO2,PR	Weight:	75G
Dimension:	10X20X15CM	Standard:	Pulse Oximeter
Power:	Built-in Rechargeable Li-ion Battery	Name:	Handheld Pulse Oxygen Meter
High Light:	medical grade pulse oximeter , handheld pulse oximeter

Wireless Bluetooth Handheld Pulse Oximeter RSD 7800 Pulse Rate SpO2 Probe

NAME:

1 Monitoring SPO2, TEMP, PR & PLETH

2 2.8 inch color TFT LCD in real time display, displayable in big font and big screen

3 BlueTooth wireless is very convenient to realize reviewing the measurements in big screen via connecting PC and to upload history data to PC for review, printing or storage

4 Long time monitoring and sleeping monitoring

5 Storage/Review trend data up to 3888 groups, data save time interval settable

6 Audio and visual alarm when parameters exceeded and sensor-off

7 Built-in rechargeable Li-ion battery, up to 15-hour running time

8 Battery capacity indicator. Automatic shutdown for power saving

P/N:

RSD 7800

INTRODUCTION:

1. General

Monitoring Parameters: SpO2,PR,PLETH,Pulse strength,TEMP

Signal sockets:SpO2 socket,TEMP socket,USB socket(for charge battery and transmit data)

2. Display screen

Type: 240 × 320 dot matrix color TFT LCD screen

Display area: 43mm×58mm

3. Functions

PLETH: The monitor can display PLETH waveform

Intelligent parameter monitoring screen: The monitor automatically selects the parameter measurements to display according to the probes connected to the monitor.

Audio and visual alarm: The speaker sounds the alarm and the parameter’s measurement will become in red to flash on the screen. Also the same when sensor-off.

Prompting: Icons of battery capacity, pulse sound switch and alarm sound switch.

Power saving: The monitor will automatic shut down to save power. The time is settable.

Trend: Storage/Review trend data up to 3888 groups, data save time being set freely

Data storage: The saved data will never be lost even if the monitor is powered off.

Communication: Transmitting the patient’s trend to a PC for display, observation, saving and printing via USB or Bluetooth wireless

4. Electrical specifications

Working Voltage: D.C. 3.7V/3000mAH

AC power adaptor

Input: AC 100 V～240V, 50/60Hz, 5VA

WARRANTY:

One years after receiving item.
