High Precision Vet Monitor , Light Weight Bedside Animal Heart Rate Monitor

Vet Animal Use 8 Inch TFT Color Screen Bedside Patient Monitor For Dog Cat Cow

P/N:

RSD 6000X V

FEATURES:

1. Professional design for vet:Cats(Small)Dogs(Middle)Horses(Large).

2. Special NIBP board for vet, alarm range, and software.

1. 8'' color TFT display, high resolution: 800x600dpi;

2. Standard 5 para ECG, SpO2, NIBP,TEMP, RESSP;

3. Seperated para module: ECG, NIBP, SpO2 module board each be independed;

4. Full touch-screen enables intuitive option by clicking on the specific parameters,

or the waveform in real time, standard configuration includes the specific parameters;

6. Multi-display: Standard, Large font, Trend Coexis, OxyCRG dynamic 7-lead ECG waveform;

7. Standby mode for Energy saving and suspend monitoring;

8. SpO2 pitch Tone Variation and Drug Dose Calculation;

9. Under status of freeze, can analyzer the waveform in time and ARR analy

11. Built-in rechargable lithium battery, continue 3H and battery volume checking;

12. TCP/IP networking platform for CMS, optional for WIFI, and enable abundant future upgrade

13. 2-USB socket, SDcard data storage, can transfer data to PC to review, and VGA output;

14. Networking capacity and TCP/IP networking platform enable abundant future upgrde;

15. Complete and flexible mounting solution for transportation and in-patient monitoring

17. Complete and flexible mounting solution for transportation and in-patient monitoring

FEATURES:

8.4" color TFT LCD screen, resolution: 800*600
5 kinds of interfaces: Standard/Big font/6-lead ECG/Trend gragh/OxyCRG
Maximum 8-channel waveforms display, the waveform color can be defined by user (7 colors)
96-hour storage and review of trend graphic gram and table, 400 groups NIBP data, 1800 alarm events
ST and arrhythmia analysis, pacemaker analysis, drug dose calculation
Anti-defibrillation design
NIBP over pressure protection
Plug-in rechargeable battery, AC/DC available
Support wire or wireless network

WARRANTY:

One years after receiving item.
