| Place of Origin: | China |
| Brand Name: | RONSEDA |
| Certification: | CE and ISO |
| Model Number: | RSD 8000 Plus |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Usd 1200 / Set |
| Packaging Details: | Box |
| Delivery Time: | 5-10 Working Days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 Set / Month |
| Parameter: | SPO2,ECG,NIBP,TEMP,PR,RESP | Screen: | 15 Inch TFT Color Screen |
|---|---|---|---|
| Weight: | 2.8 KG | Dimension: | 15X42X32 CM |
| Standard: | SpO2 Sensor,ECG Cable,Temperature Probe,NIBP Cuff,NIBP Hose,Power Cable | Optional: | Touch Screen,EtCO2,IBP,Printer |
| High Light: | multipara patient monitor,ambulance patient monitor |
||
15" Multi Parameter Portable Ambulance Patient Monitor with ETCO2
NAME:
P/N:
RSD 8000 Plus
INTRODUCTION:
1. Spo2 Pitch Tone Variation;
2. Hemodynamic Calculations;
3. Waveforms are user selectable;
4. Standby mode for energy saving and suspend monitoring;
5. Separated parameter board: main, ECG, SPO2, NIBP board are independent;
6. Display:15" color TFT screen, high resolution: 1024×769 dpi;
7. Time delay:Time delay switch-off function to save data when monitor turn off suddenly;
8. Fanless: Use special fanless cooling technology in the device to provide users quiet environment;
9. Language: Built-in 8 language for choose (English, Chinese, Turkish, Spanish, French, Russian, German, Italian);
10. Advance patient Manage: gender, full name, ID no., room no., bed no., weight,height, blood type, paced or not, remakes
SPECIFICATIONS:
|
ECG
Lead mode: 3 Leads or 5 Leads
Lead selection: I,II,III,AVR,AVL,AVF,V
Gain:X0.25,X0.5,X1,X2,Auto
Heart Rate:15-300BPM(Adult) 15-350BPM(Neonatal)
Resolution:1 BPM
Accuracy:±1%
ST measurement Range: -2.0+2.0mV
Pacemaker: Yes
ARR detecting: Yes
Electrode offset potential: ±300mV
Leakage current: <10uA
NIBP
Work mode: Manual, Auto, Continuous
Measure Range:
Adult: SYS: 40-270mmHg
DIA: 10-215mmHg
MEAN:20-235mmHg
Pediatric:
SYS:40-200mmHg
DIA: 10-150mmHg
MEAN:20-165mmHg
Neonatal:
SYS:40-135mmHg
DIA:10-100mmHg
MEAN:20-110mmHg
Resolution:1mmHg
Measurement Type :SYS,DIA,MEAN
|
SpO2
Measure Range:0-100%
Resolution:1%
Accuracy:2%(70-100%),,0-69%,upspecified
Pulse Rate:20-300BPM
Resolution:1BPM
Accuracy:±2BPM
RESP
Measure Range:0-150RPM
Resolution:1BrPM
Accuracy:±2%
TEMP*2
Measure Range:0-50C
Resolution:0.1C
Accuracy:±0.1C
IBP:
Measure range:
ART:0-300 mmHg
PA:-6-120 mmHg
CVP/RAP/LAP/ICP:-10-40 mmHg
P1/P2:-10-300 mmHg
Accuracy: ±2% or ±1 mmHg
Environment:
Operating Temperature: 59°to 95°F(15°to 35°C)
Storage Temperature: 23°to 122°F(-5°to 50°C)
Operating Humidity: 15℅ to 90℅,non-condensing
|
STANDARD CONFIGURATION:
Dual TEMP
Dual IBP
ETCO2 (side stream)
Thermal recorder
Wall mount
Trolley
WARRANTY:
One years after receiving item.
